Introduction:
TOC-30 TOC Total organic carbon analyzer realize the water supply system on-line, continuous real-time detection, both to meet your application, and can save investment.This instrument adapt The principle of UV oxidation ,TOC= TC – TIC
Features :
- Used stainless steel 304 as external material.
- The use of modular design, according to the customer’s system needs to function configuration
- Provide customers with two options, both single-point real-time and multi-point time-sharing online monitoring;
- With waterproof splash design, can work under high humidity environment and high temperature.
- Using the latest high performance CPU processor, the expansion of the instrument function, improve the processing speed and accuracy
- Large capacity storage space, guarantee the long-term storage of historical records
- High precision flow control design, which ensures the stability of the TOC test accuracy and oxidation process
- With automatic upper limit alarm output function, the data is abnormal, timely reminder
- Touch screen design, user-friendly man-machine interface, simple operation
Technical parameters:
| Model | TOC-30 |
| Power requirements / power | 100-240VAC, 50HZ, 120W |
| Conductivity detection range | 0.055μs / cm-8.000μs / cm |
| Measuring range | 0.001mg / L-1.5mg / L (1500ppb) |
| measurement accuracy | ± 3% |
| Resolution | 0.001mg / L |
| Response time | Within 5 minutes |
| Detection limit | 0.001mg / L |
| Sample temperature | 1-95 ℃ |
| Ambient temperature | 5-65 ℃ |
| Scope of application | online test |
| authority management | User password login, level 4 permissions, meeting FDA 21 CFR PART 11 |
| Print function | External mini printer |
| history record | ≥5 years storage |
| data backup | Support U disk export data |
| Display | Color touch screen |
| Overall dimensions (mm) | 300 × 210 × 250 (length × width × height) |
| weight | 8.5KG
|
