Adoption of low-temperature liquid circulation equipment of compression refrigeration methods can cool the tube, the reaction bottles directly and so on to have chemical reaction under low-temp and store chemical and biological products under low-temperature. Besides, it can also be combined with Rotary Evaporator, Vacuum Freeze-drying Box, and multi-purpose Circulating Water Vacuum Pump.
Features
- Large-capacity open bath combined with outside loop can not only be used as freezing tanks, but also provide cooling fluid outside.
- Digital setting and display of temperature, easy to operate.
- Refrigeration compressors and other key parts adopt products with famous brands of the United States, Germany, and France and have high reliability and efficiency.
- Circulating system adapts SUS 304, 316 and macromole anti corrosion substance, which can prevent rust, corrosion, and low temperature liquid pollution.
Specifications:
| Model | LLCP-5-10 | LLCP-5-20 | LLCP-10-20 | |
| Temp. Range(°C) | -10~RT | -20~RT | ||
| Temp. Stability(°C) | ±1 | |||
| Cooling capacity (W) | 10°C | 1250 | 1150 | 1700 |
| 0°C | 970 | 880 | 1200 | |
| -10°C | 650 | 600 | 700 | |
| -20°C | – | 320 | 370 | |
| Flow(L/min) | 12 | |||
| Lift(m) | 5~7 | |||
| Bath volume(L) | 5 | 5 | 10 | |
| Bath opening(mm) | ф210×180 | ф210×180 | ф210×250 | |
| Ambient temp.(°C) | 5~25 | |||
| Power Supply(V/Hz) | 220/50 | |||
| Overall Power(W) | 600 | 600 | 1100 | |
| Case Material | SPCC steel with powder coating | |||
| Dimensions(mm)L×W×H | 465×325×730 | 465×325×730 | 510×365×800 | |
| Weight(kg) | 41 | 41 | 50 | |
| Model | LLCP-10-30 | LLCP-20-30 | LLCP-30-30 | LLCP-50-30 | LLCP-100-30 | |
| Temp. range(°C) | -30~Room temp | |||||
| Temp. stability(°C) | ±1 | |||||
| Cooling capacity (W) | 10°C | 1860 | 2550 | 3240 | 10000 | 17600 |
| 0°C | 1240 | 1750 | 2820 | 7500 | 12000 | |
| -10°C | 780 | 1070 | 1810 | 4600 | 7500 | |
| -20°C | 310 | 720 | 1030 | 2570 | 6500 | |
| -30°C | 50 | 300 | 520 | 1040 | 2900 | |
| Flow(L/min) | 12 | 12 | 12 | 30 | 67 | |
| Lift(m) | 5~7 | 5~7 | 5~7 | 10~12 | 22 | |
| Bath volume(L) | 10 | 20 | 30 | 50 | 100 | |
| Bath opening(mm) | ф210×250 | ф280×300 | ф320×235 | ф400×280 | ф400×400 | |
| Ambient temp.(°C) | 5~25 | |||||
| Power Supply(V/Hz) | 220/50 | 380/50 | ||||
| Overall Power(W) | 1100 | 1400 | 1800 | 2900 | 5300 | |
| Case Material | SPCC steel with powder coating | |||||
| Dimensions(mm) | 510×365×800 | 575×495×965 | 665×545×1010 | 1080×675×1305 | 1210×740×1400 | |
| Weight(kg) | 50 | 90 | 100 | 300 | 400 | |
| Model | LLCP-30-40 | LLCP-50-40 | |
| Temperature range(°C) | -40~Room temp | ||
| Temperature stability(°C) | ±1 | ||
| Cooling capacity (W) | -10°C | 3670 | 7205 |
| -20°C | 2310 | 4950 | |
| -30°C | 1100 | 2450 | |
| -40°C | 480 | 1500 | |
| Flow(L/min) | 12 | 30 | |
| Lift(m) | 5~7 | ||
| Bath volume(L) | 30 | 50 | |
| Bath opening(mm) | ф320×235 | ф400×280 | |
| Ambient temperature(°C) | 5~25 | ||
| Power Supply(V/Hz) | 380/50 | ||
| Overall Power(W) | 2400 | 5200 | |
| Case Material | SPCC steel with powder coating | ||
| Dimensions(mm) | 665L×545W×1010H | 1055L×850W×1345H | |
| Weight(kg) | 100 | 150 | |
| Model | LLCP-20-80 | LLCP-50-80 | LLCP-100-80 | |
| Temperature range(°C) | -80~Room temp | -80~Room temp | -80~-40 | |
| Temperature stability(°C) | ±1 | |||
| Cooling capacity (W) | -40°C | 510 | 1150 | 2400 |
| -60°C | 210 | 760 | 1500 | |
| -80°C | 80 | 300 | 600 | |
| Flow(L/min) | 12 | 30 | 30 | |
| Lift(m) | 5~7 | 10~12 | ||
| Bath volume(L) | 20 | 50 | 100 | |
| Bath opening(mm) | ф280×300 | ф400×235 | ф400×400 | |
| Ambient temperature(°C) | 5~25 | |||
| Power Supply(V/Hz) | 220/50 | 380/50 | ||
| Overall Power(W) | 2400 | 4800 | 9200 | |
| Case Material | SPCC steel with powder coating | |||
| Dimensions(mm) | 905L×750W×1100H | 1010L×785W×1100H | 850L×1060W×1280H | |
| Weight(kg) | 150 | 350 | 400 | |
