APPLICATIONS:
This device provides both cooling and heating constant environment which can be widely used in many industries such as pharmacy, chemical industry and biology.
FEATURES:
- LCD Touch Display
- Automated control, easy operation
- PLC program machine interface
- 50 stage temperature control programmable
- Can measure the temp. of connected reactor
- Over-temperature protected
- It is consisted by 3 parts: refrigerating system, heating system and pre-cooling system. Three systems can be combination used and also run independently.
- Rapid heating and cooling, temperature increased and lowered continuously.
- Widely range of temperature control; no need of changing heat-conducting medium in the whole course, low consumption of heat-conducting medium.
- Hermetic circulating system, less volatile and oxidation of medium, less moisture to be absorbed in the air, which can make the service life of heat transfer fluid longer.
- High temperature cooling and refrigeration function can lower from high temperature level directly(e.g.: can directly cooling from 200°C).
- Refrigeration heat exchanger adopts complete brazing type, small space occupied and high efficiency of heat exchanging.
- Liquid level display function can monitor the liquid level at any time to avoid lacking of liquid.
- Multiple protection functions including high temperature cut off, scram, time delay, leakage, over-current, over-heated can fully ensure the safety using.
- Air cooled type
Specifications
| Model |
HRHC-series |
|||||||||
|
20-200-30 |
20-200-40 |
20-200-80 |
50-200-30 |
50-200-40 |
50-200-80 |
100-200-30 |
100-200-40 |
100-200-80 |
||
|
Temp. Range (°C) |
-30~200 |
-40~200 |
-80~200 |
-30~200 |
-40~200 |
-80~200 |
-30~200 |
-40~200 |
-80~200 |
|
|
Temp. stability (°C) |
±2 |
±2 |
±2 |
±2 |
±2 |
±2 |
±2 |
±2 |
±2 |
|
|
Heating Power (kw) |
3 |
3 |
3 |
6 |
6 |
6 |
12 |
12 |
12 |
|
|
Power (kw) |
4.58 |
5.69 |
7.93 |
9.13 |
11.2 |
15.59 |
18.16 |
21.76 |
29.22 |
|
|
Voltage (V/Hz) |
1p-220/50 |
3p-380/50 |
3p-380/50 |
3p-380/50 |
3p-380/50 |
3p-380/50 |
3p-380/50 |
3p-380/50 |
3p-380/50 |
|
|
Refrigerant |
R22 |
R404a |
R404a, R23 |
R22 |
R404a |
R404a, R23 |
R404a |
R404a |
R404a, R23 |
|
|
Cooling capacity (KW) |
200°C |
1.7 |
1.7 |
1.7 |
3 |
3 |
3 |
3 |
3 |
3 |
|
10°C |
2.6 |
4.3 |
4.3 |
7.5 |
8.2 |
8.2 |
8.2 |
18 |
18 |
|
|
-10°C |
1.1 |
3.1 |
3.1 |
4.6 |
6.2 |
6.2 |
6.2 |
12 |
12 |
|
|
-20°C |
0.7 |
2.3 |
2.3 |
2.5 |
4.5 |
4.5 |
4.5 |
7.3 |
7.3 |
|
|
-30°C |
0.3 |
1.2 |
1.2 |
1.0 |
2.5 |
2.5 |
2.5 |
4.0 |
4.0 |
|
|
-40°C |
– |
0.3 |
2.0 |
– |
1.0 |
5.0 |
– |
1.7 |
10 |
|
|
-60°C |
– |
– |
1.4 |
– |
– |
3.0 |
– |
– |
6 |
|
|
-80°C |
– |
– |
0.45 |
– |
– |
1.0 |
– |
– |
2.5 |
|
|
Circulating |
Power (w) |
280 |
280 |
280 |
280 |
280 |
280 |
1100 |
1100 |
1100 |
|
Flow |
30(L/min) |
30(L/min) |
30(L/min) |
30(L/min) |
30(L/min) |
30(L/min) |
90(L/min) |
90(L/min) |
90(L/min) |
|
|
Lift (m) |
10 |
10 |
10 |
10 |
10 |
10 |
15 |
15 |
15 |
|
|
Material |
Tank |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
|
Pipe,valve |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
|
|
Connector |
3/4’’ |
3/4’’ |
3/4’’ |
3/4’’ |
3/4’’ |
3/4’’ |
3/4’’ |
3/4’’ |
3/4’’ |
|
|
Medium capacity (L) |
7.5 |
7.5 |
9 |
11.5 |
11.5 |
16 |
18 |
18 |
20 |
|
|
Dimensions (mm)L×W×H |
740×710×1330 |
820×810×1330 |
1225×900×1530 |
910×810×1430 |
1110×820×1430 |
1250×900×1535 |
1255×955×1590 |
1215×1010×1865 |
1660×1150×1865 |
|
