Applicable Standard
SH/T 0722
ASTM D6082
Performance Characteristics
The apparatus is applied to measuring the foam characteristics of lubricating oil (especially referring to the transmission liquid and engine oil) at 150℃.
The apparatus employs the foreign advanced PID self-tuning temperature regulating system with digital display and low deviation as ±0.2℃.
The air bath heating is safe and environment-protective.
Heat-resistant quartz glass measuring cylinder is safe and reliable.
The strong circulating fan guarantees the temperature equalization.
The light with adjustable luminance is installed in the bath to facilitate the observation of the test.
Each group of test has a respective temperature control to ensure the accuracy of the test temperature.
Stainless steel diffuser head made in U.S.A is equipped.
No-oil-feed air pump guarantees the airflow supply.
The timing and alarming device is included.
Technical indicators
Working power supply: AC220V±10% 50Hz
Heating power: <2.5KW
Air bath temperature: 150±1.0℃
Oil specimen temperature: 150±1.0℃
Airflow velocity: 200±5ml/min
No. of test orifices: 4
Diffuser head seepage rate: from 3000 to 6000 ml/min
