Characteristics：
1.For 4~6 minutes rapidly sterilizing.
2.Digital display of working status,touch type key.
3.With 3 fixed cycles of water adding,temperature rising,sterilizing,drying steam discharging controlled automatically.
4.The whole process of water adding,temperature rising,sterilizing,drying steam discharging controlled automatically.
4.Steam-water inner circulation system:no steam discharge,and the environment for sterilizing will be clean and dry.
5.Exhaust the cool air automatically.
6.Safe protection of water lacking.
7.Door safety lock system.
8.With four stainless steel sterilizing plates.
9.The chamber of the sterilizer is made of stainless steel.
10.Automatically shut off with beep reminding after sterilization.
11.With drying function.
Technical data:
| MODEL | SA-BXD20D | SA-BXD24D | SA-BXD35D
(250B35) |
SA-BXD50D
(250B50) |
| Chamber volume | 20L | 24L | 35L | 50L |
| Chamber size (mm) | φ250×420 | φ250×520 | φ300×500 | φ340×550 |
| Working pressure | 0.22Mpa | 0.22Mpa | 0.22Mpa | 0.22Mpa |
| Working temperature | 134°C | 134°C | 134°C | 134°C |
| Temp. range | 105-134°C | 105-134°C | 105-134°C | 105-134°C |
| Timer | 0-99 min | 0-99 min | 0-99 min | 0-99 min |
| Heat average | ≤ ± 1°C | ≤ ± 1°C | ≤ ± 1°C | ≤ ± 1°C |
| Power | 1.5 KW
AC220V 50Hz |
1.5 KW
AC220V 50Hz |
2.7 KW
AC220V 50Hz |
2.7 KW
AC220V 50Hz |
| Plate size(mm) | 340×200×30 | 400×200×30 | 400×200×30 | 500×250×30 |
| Plate quantity | 3 pcs | 3 pcs | 4 pcs | 4 pcs |
| Dimensions(mm) | 480×480×380 | 580×480×384 | 730×550×510 | 770×600×540 |
| Packing size (mm) | 700×580×500 | 800×580×500 | 810×680×650 | 880×730×700 |
| G. W/N.W | 43/40 kg | 50/45 kg | 95/78 kg | 112/93 kg |
