Application
It is widely used to study microorganisms, viruses, bacteria culture, fermentation, hybridization, and biochemical reactions and cell organizations. The temperature, the oscillation frequency, amplitude, culture and enzyme engineering studies and other aspects of the different requirements of providing effective help. Has a broad and important role in medicine, biology, molecular, pharmaceutical, food, environmental protection and other research applications.
Features:
- Large-screen backlit LCD display
- Freely set the incubation time
- Used long-life brushless DC motor with low noise
- Energy conservation and efficiency infrared heating tube
- Fluorescent lamp inside the working chamber
- Quiet fan forced convection
- With restored when power outages and open encryption function, power auto off when door opening.
- Super fuzzy PID control
- Over-temperature alarm and cut off power
- Streamlined appearance, stainless steel mirrors, glass windows, electrostatic spray housing
Specifications:
| Product name |
Thermostatic shaking incubator |
Thermostatic shaking incubator |
|
|
Model |
TSI-200 |
TSI-200D |
|
|
Sharking frequency |
30-300rpm |
||
|
Sharking accuracy |
±1rpm |
||
|
Shake plate amplitude |
Ф20mm |
||
|
Temp. range |
Ambient temp+5 ~ 65°C |
4 ~ 65°C |
|
|
Temp. adjust accuracy |
±0.1°C |
||
|
Temperature uniformity |
±1 (at 37°C) |
||
|
Temperature fluctuation |
±0.3°C(at 37°C) |
||
|
control method |
PID controller |
||
|
Maximum capacity |
500ml×24 or 100ml×60 |
||
|
Timing range |
0-9999min (h) |
||
|
Shake plate size (mm) |
439×528mm * 2 pcs |
||
|
Chamber layer |
2 layers |
||
|
Standard configuration |
Fixture |
||
|
Power (kw) |
1 |
1.3 |
|
|
power supply |
AC220±10%50~60Hz |
||
|
Dimensions (W*D*H) |
740*740*1085 |
740*755*1235 |
|
|
Packing size (W*D*H) |
830*810*1200 |
830*830*1350 |
|
|
NW |
150 |
170 |
|
