Product Feature:
■ Double paddle, large work space design;
■ Studio is processed by quality stainless steel mirror panel, easy to clean;
■ Double doors hollow glass door, easy to observe the internal situation; the side is with a test hole to facilitate to test sample and to meet the demand for oxygen;
■ Equipped with lights and UV germicidal lamp, easy to observe and sterilization
■Imported CFC-free refrigeration compressors, refrigeration unique work designed to ensure that the compressor does not overheat due to their own self-protection shut down, so as to achieve high-quality temperature effect;
■ Centrifugal circulating air duct, forced to work indoor air flow, the temperature more uniform;
■ High pressure brushless DC motor control scheme, the number of revolutions measurement precision, long life, maintenance-free; available for reversing the work setting;
■ Having a gate function, automatic door stops;
■ Multidimensional driven, smooth operation and long service life;
■ LCD large-screen LCD display and a color touch screen program temperature control system in the form of two control options to meet your needs;
■ With a timer function, time setting range 0 to 9999 (minutes) hours;
■ With power and memory function, without any interruption, crash cause data loss;
■ With over-temperature alarm and automatic power-off function;
■Has a self-diagnostic function;
Main Technical Parameters:
| Product name | Vertical large capacity | Vertical large capacity | Vertical large capacity | Vertical large capacity | ||
Model | TSI-500 | TSI-500R | TSI-500A | TSI-500AR | ||
LCD | ||||||
Sharking frequency | 10-300rpm | |||||
Sharking accuracy | ±1rpm | |||||
Shake plate amplitude | Ф26mm | Ф35mm | ||||
Temp. range | room temperature | 4～65℃ | room temperature | 4～65℃ | ||
Temp. adjust accuracy | ±0.1℃ | |||||
Temperature uniformity | ±1 （at 37℃） | |||||
Temperature fluctuation | ±0.3℃（at 37℃） | |||||
control method | P．I．D Microcomputer intelligent control | |||||
Size / number of plate | 830×500mm/2pcs | |||||
Maximum capacity of single layer | 100m×77or250ml×45or500ml×37or1000ml×18or2000ml×13 | |||||
Single standard capacity | 100m×45or250ml×35or500ml×24or1000ml×12or2000ml×8 | |||||
standard configuration | 2 layers（Lower fixing clamp 1000ml×12，Upper fixed clamp | |||||
Timing range | ||||||
Power (kw) | 1.8 | 2.1 | 1.9 | 2.2 | ||
power supply | AC220±10% 50～60Hz | |||||
Dimensions (W*D*H) | 1060*800*1470 | |||||
Packing size (W*D*H) | 1190*895*1640 | |||||
NW | 280 | 300 | 420 | 440 | ||
Note:
1, Performance parameter testing under no-load conditions: ambient temperature20 ° c, humidity 50%RH
2: Working ambient temperature: 5-25℃
3, In order to give full play to the best use of the equipment,all products at the factory in accordance with the standard fixture configuration capacity configuration shall prevail.
Optional Configuration Function
| fittings | function |
True color touch screen program temperature control system | 1、Adopted 16 byte 4.3-inch true color touch screen computer control system, resistive touch screen, high touch accuracy, stability and reliability; |
6、optional buy our company matching computer software, real-time monitoring equipment through Ethernet | |
Micro printer | Print control data according to the need |
485 interface remote control system | Can be based on the needs of the work of remote control and data analysis, export |
USB interface | According to the needs of the work, export of experimental data, does data analysis |
