Features:
It is particularly suitable for measuring chemical, biological and physical experiment in low temperature, it it is used for grouping instrument of pharmaceutical health ,foodstuff ,chemistry , and university or academic institution, including reaction vessel rapid cooling, low temperature moulds ,frozen processing fixture and low testing machine cooling .
- Chemistry, biological area: atomic absorption ICP, ICP-MS, MR, CCD, biological fermented, Chemical reactor , synthetic tank and so on.
- Material area: SEM TEM X ray scattering, X fluorescence , magnetron sputtering vacuum coating machine laser.
- With low noisy and high reliability, International famous fully closed compressor ensure long-term work.
- Circulating pump is domestic high performance or high pressure vane pump imported with original packaging , pressure vane pump can be adjusted, high quality.
- Closed circulating system can avoid refrigerating medium evaporation and pollution, save energy.
- Circulating system is equipped with filter apparatus, clean refrigerating medium avoids instrument lin clogging
- Use environment friendly refrigerating and medium not having component of chlorofluorocarbon, Be suite for international environment refrigerating standards.
- Design in a new style , little volume ,beautiful profile.
- With built-in liquid-level monitor ,liquid-level inside the bath can be checked visually.
- Circulating system is equipped with pressure gauge, displays circulating system pressure.
- Many different models can meet the customers’ different requirements.
- Panels on the both sides can be removed easily, convenient to maintain and clean.
Specifications:
| Model | LCC-10-1000 | LCC-10-2000 | LCC-10-3000 | LCC-10-6000 |
| Temp. range °C | -10~25 | -10~25 | -10~25 | -10~25 |
| Temp. stability °C | ±2 | ±2 | ±2 | ±2 |
| Display | Digital | Digital | Digital | Digital |
| Temp. Sensor | PT100 | PT100 | PT100 | PT100 |
| power supply (V/Hz) | 220/50 | 220/50 | 220/50 | 380/50 |
Cooling capacity (W) @15°C | 1000 | 2000 | 3000 | 6000 |
| Total Power (W) | 1200 | 1408 | 1920 | 3325 |
| Refrigerant | R134a | R134a | R134a | R134a |
| Power of pump (W) | 280 | 280 | 280 | 370 |
| Pump flow (L/min) | 30 | 30 | 30 | 40 |
| Pressure (bar) | 1 bar | 1 bar | 1 bar | 1.5 bar |
| Outlet port | 1/2’’ | 1/2’’ | 1/2’’ | 3/4’’ |
| Tank material | SUS304 | SUS304 | SUS304 | SUS304 |
| Dimensions (mm) L×W×H | 675×426×695 | 675×456×775 | 740×490×830 | 1020×635×1030 |
| Weight (kg) | 70 | 80 | 108 | 150 |
| Security | Delay, leakage, overcurrent , overheating | |||
Remark:
- Voltage can be change to 110V/60 Hz
- Can be change to adjustable high circulation pressure from 1 ~ 10 bar (Model: G)
Specifications:
| Model | LCC-30-1000 | LCC-30-700 | LCC-30-1000 | LCC-30-2500 | |
| Temp. range °C | -30~25 | -30~25 | -30~25 | -30~25 | |
| Temp. stability °C | ±2 | ±2 | ±2 | ±2 | |
| Display | Digital | Digital | Digital | Digital | |
| Temp. Sensor | PT100 | PT100 | PT100 | PT100 | |
| power supply (V/Hz) | 220/50 | 220/50 | 220/50 | 380/50 | |
| Cooling capacity (W) | 0°C | 1240 | 1750 | 2820 | 7500 |
| -10°C | 780 | 1070 | 1810 | 4600 | |
| -20°C | 300 | 700 | 1000 | 2500 | |
| -30°C | 150 | 300 | 520 | 1040 | |
| Total Power (W) | 1255 | 1615 | 2170 | 3634 | |
| Refrigerant | R410a | R410a | R410a | R410a | |
| Power of pump (W) | 280 | 280 | 280 | 370 | |
| Pump flow (L/min) | 30 | 30 | 30 | 40 | |
| Pressure (bar) | 1 bar | 1 bar | 1 bar | 1.5 bar | |
| Outlet port | 1/2’’ | 1/2’’ | 1/2’’ | 3/4’’ | |
| Tank material | SUS304 | SUS304 | SUS304 | SUS304 | |
| Dimensions (mm) L×W×H | 675×426×695 | 675×465×775 | 740×490×830 | 1020×635×1030 | |
| Weight (kg) | 70 | 80 | 108 | 150 | |
| Security | Delay, leakage, overcurrent , overheating | ||||
Remark:
- Voltage can be change to 110V/60 Hz
