Specifications
- Multi function: Ultrasonic, microwave or ultrasound-microwave three methods;
- light wave power / frequency : 50-850W adjustable / wave frequency infrared segment( microwave frequency : 2450 MHz)
- ultrasonic power / frequency : 10-500W / frequency 20~25 KHz;
- Light wave ( microwave ) method: non- pulsed continuous heating ;
- ultrasound method: low-power ultrasonic transducer is directly connected with the reaction vessel; low noise, sound and vibration ( energy ) efficiency close to 100% ;
- Light wave ( microwave ) control mode : time control & power control;
- Program control : can preset a variety of methods
- Sample volume: standard 0.5-500mL ( special specifications can be customized to user requirements ) ;
- chamber volume :5~10 L;
- Voltage supply : 220 V ± 10% AC, 50 Hz;
- Power : 3000W;
- microwave leakage in line with national standards
- sensor with ultra mild abnormal protection , high reliability security
- External made by stainless steel , very durable
Specifications:
| Model | UE-IIDM |
Ultrasonic power | 500W |
Ultrasonic frequency | 20KHz |
Wave power | 50~580W adjustable |
Microwave Power | 1000W |
Temperature range | RT ~ +100°C |
Wave frequency | Far Infrared |
Handling capacity | 0.5-500mpl |
Vibration head diameter | Φ3-6 |
