Bath pot features
- Transparent shield, thermal insulation, energy saving, explosion-proof, splash-proof, rust-proof, anti-pollution, improve safety performance.
- The water bath pot, small size, rapid warming. Heating pot using Teflon composite pot, easy to clean. Steam guide rail combines the advantages of rotary sealing system abroad.
- RE-3000 is integrated oil bath and water bath dual used rotary evaporator developed by our factory. whole design elegant, reasonable and compact, simple & convenient for operation, precise temperature control and reliable performance. Strong, durable. Specially designed steam pipe, vacuum sealing system consist of PTFE composite materials, long life, good sealing effect, processed by a special process technology to enhance sealing, corrosion resistance and abrasion resistance. Steam sealed tube with integrated design, to prevent cross-contamination, and extremely easy to disassembly & clean.
Features of 3L Rotary Evaporator
- Water bath and oil bath dual
- Temperature is higher than the set temperature,the heating tube automatically stop heating.
- 8-liter capacity water bath can use 3000ML-5000ML flask.
- Rocker typeelectric up & down, fast automatic up and down,0-150 mm
- Evaporating flask rotare speed 0-200 r / min, power 40W
- Cooler: vertical, inclined, cold pit
- High temperature resistance qualified glass double reflux
- intergrated standard mouth condenser pipe with standard mouthcollected bottles
- Feeder: Valve type feeding tube with tetrafluoroethylene tube, tetrafluoroethylenepipes and water retaining ring.
- Sealing ring: PTFE vacuum sealing ring
- Rocker typebuttons: Upper rocker pressing host machine to up, lower rocker pressing the host machine to down.
- Nut with ring: rotate clockwise automatically fasten bottle, rotate anticlockwisefast to shirk rotating Stepless speed control by Knob.
- Angle adjusting: Loosen or tighten with
- Hostusing stainless steel, rust-proof aluminum, special engineering plastics, compact, attractive appearance, durable & practical.
- Equipped with air duct type cooling device.
Specifications of 3L Rotary Evaporator
| Model | RE-3000A | RE-3000B | RE-3000E |
| Glass Material | GG-17 | ||
| Bracket Material | Aluminium alloy | ||
| Material of Pan | Aluminium alloy+Teflon composite pot, fully closed heating,250*130mm | ||
| Rotating bottle volume | 3L ￠50Flange mouth | ||
| Collect bottle volume | 2L 35#Ball mill | ||
| vacuum degree | 40W | ||
| Rotating power | 0-180rpm | ||
| Rotating speed | 1.5KW | ||
| heating power | 0-99°C | ||
| Temp. control range | ±1°C | ||
| Lifting power | 15W | ||
| Lifting trip | 120mm | ||
| Voltage/frequency(V/Hz) | 220V/50Hz | ||
| Shape size(mm) | 660*420*830 | ||
| Packing dimensions(mm) | 630*560*540 0.19square | ||
| Packing weight (KG) | 30 | ||
| e-cvt Display mode | N/A | digital display | LCD screen |
| Speed display mode | digital display | ||
| Temperature sensor | PT100 sensor digital display | ||
| temperature control | Intelligent Temperature Control | ||
| Sealing method | TFL+FL Bidirectional Seal | ||
| condenser | Host automatic lifting | ||
| Lifting mode | Vertical condenser100*510mm | ||
| Continuous Feeds | 19#Label feeding valve | ||
