Features of NIR Spectrophotometer
- Transmission NIR, mainly used for liquid samples qualitative and quantitative analysis, applies to gasoline, drinks, milk and other areas of nutrients, water chemistry and other physical properties of the rapid non-destructive analysis determination.
- Original imported(Japan) indium gallium arsenic detector has a high spectral signal-to-noise ratio.
- Small and lightweight instrument with compact structure design, convenient for field test
- Built-in standard material of the instrument automatically performs baseline and wavelength correction in real time, effectively reducing drift and providing more stable spectral data
- Single-channel whole spectrum scanning.
- Easily updated.
- Fast scanning, wavelength calibrates time from 900nm to 2500nm less than 1
- Built in SCM technology, auto 0% and auto background subtraction.
Applications and Features of NIR Spectrophotometer
Application field: liquid samples (gasoline, drink and milk, etc.)
Optical system: grating monochromator
Detector: InGaAs
Interface: USB
Specifications of NIR Spectrophotometer
| Model | SP-NIR430 |
| measurement method | Transmission cell |
| detector | Japan Hamamatsu Refrigeration InGaAs |
| Spectral bandwidth nm | 8 |
| Wavelength range nm | 900 ~ 2500 |
| Wavelength accuracy nm | ≤0.2 |
| Wavelength repeatability nm | ≤0.05 |
| Stray light% | ≤0.1 |
| Abs Noise Abs | ≤0.0005 |
| Analysis time | 1 minute (adjustable) |
| Data transmission method | USB2.0 |
| Calibration technology | MPLS Improved Least Squares Regression Calibration Technique DPLS Spectrum Identification and Qualitative Analysis Technology |
Standard Package
| Standard configuration items | Qty |
| Near infrared spectrophotometer host | One |
| Fuse (2A) | 2 each |
| Product Warranty | One |
| Power cable | One |
| USB communication cable | One |
| Packing List | One |
| Product Certificate of Conformity | One |
| Instruction Manual | One |
| 10mm rectangular cuvette (quartz) | One box (two pieces) |
| 2mm rectangular cuvette (quartz) | One box (two pieces) |
| USB disk | One |
| Data processing software (in the preset U disk) | One |
