Features
- Microprocessor control, operated by touch panel, LED display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
- Brushless converter motor which has high torque, High speed bearing from Europe, smoothly running and maintenance-free.
- Multistage damping system, low noise and slight vibration，
- Steel body, stainless steel centrifugal chamber, imports of keycomponents, durable and easy to clean.
- Over-speed, door interlock, imbalance protection. The rotor can be disinfected at high temperature & high pressure, ensure safety.
- Proprietary air current design, small temperature-rise of centrifuge chamber，effective protection of the sample.
Technical Parameter
| Model | CF-T18G |
| Max Speed | 18000r/min |
| Max RCF | 21500* g |
| Max Capacity | 300ml |
| Speed Accuracy | ±50r/min |
| Time Range | 0-99min |
| Power Supply | AC 220V 50Hz / AC110V 60Hz 18A |
| Noise | ≤ 65dB |
| Dimension | 400*350*340mm |
| Weight | 25kg |
Rotors
| No. | Centrifuge Host | Rotor capacity | MAX. RPM | Max RCF(×g) | Suit tube |
| 6 | Angle | 12×1.5ml | 18600 | 23950 | Φ10×42 |
| 11 | Angle | 18×0.5ml | 18600 | 23950 | Φ8×32 |
| 9 | Angle | 24×1.5/2.0ml | 15000 | 21000 | Φ10×42 |
| 12 | Angle | 10×5ml | 16000 | 17420 | Φ14×54 |
| 16 | Angle | 12×10ml | 15000 | 23120 | Φ16×81 |
| 22 | Angle | 6×50ml | 13000 | 17380 | Φ28×105 |
| 31 | Angle | 4×100ml | 10000 | 9690 | Φ38×124 |
| 56 | Angle | 48×1.5ml | 13000 | 14740 | Φ8×32 |
| 52 | Angle | 8×15ml | 12000 | 16740 | Φ16×118 |
| 44 | Swing | 2×48 Holes | 3000 | 1400 | Microplate |
| 63 | Swing | 4×50/100ml | 5000 | 4390 | Φ38×124 |
| 69 | Swing | 4×500ml | 4000 | 3580 | Φ80×140 |
| Adaptor | 12×50ml/8×100ml | 4000 | 3580 | ||
| 70 | Swing | 4×250ml | 4000 | 3500 | Φ64×113 |
| Adaptor | 8×50ml/36×10ml | 4000 | 3500 | ||
| 77 | Swing | 32×10/15ml | 4000 | 2810 | Φ16×85-118 |
| 81 | Swing | 8×50/100ml | 4000 | 2810 | Φ38×124 |
| 83 | Swing | 48×5/7ml | 4000 | 3500 | Suit for Long/short tube |
| 75 | Swing | 72×5/7ml | 4000 | 3500 | Suit for Long/short tube |
| 85 | Swing | 96×5/7ml | 4000 | 3580 | Suit for Long/short tube |
