Features
- Electromagnetic Force Compensation Technology.
- Aluminum Alloy die cast base and SS304 platter.
- Super Bright LCD display with backlight.
- RS232C Interface
- Clear Glass Windshield as standard.
- Over load protection, Bubble Level Adjustment, Under hook
- Full capacity Subtraction
- Multi Weighing unit conversation g/mg/ct/oz.
- Check Weighing, Parts counting, percentage weighing
- Universal power adaptor supplied as standard
- Certificated calibration weight supplied as standard.
- Internal calibration or external calibration for your choice.
- CE approval.
Specifications:
| Model: | AB1004 | AB1104 | AB1204 | AB1604 | AB2004 | AB2104 | AB2204 | AB3004 | AB3104 | AB3204 |
| Max. Capacity | 100g | 110g | 120g | 160g | 200g | 210g | 220g | 300g | 310g | 320g |
| Min. Capacity | 10mg | 10mg | 10mg | 10mg | 10mg | 10mg | 10mg | 10mg | 10mg | 10mg |
| Division | 0.0001g | |||||||||
| Verification scale value | 0.001g | |||||||||
| Repeatability | ±0.0002g | |||||||||
| ±0.5e | 0≤m≤50000 | |||||||||
| ±1.0e | 50000<m≤200000 | |||||||||
| ±1.5e | 200000<m | |||||||||
| Settling time | ≤8seconds | |||||||||
| Operating temperature | 17.5°C~22.5°C, fluctuation range<1°C/h | |||||||||
| Calibration | External or Internal (optional) | |||||||||
| Relative humidity(RH) | 50%~75% | |||||||||
| Pan size | Ф80mm | |||||||||
| Windshield size | 225mm*220mm*265mm(L*W*H) | |||||||||
| Dimension | 340mm*215mm*350mm(L*W*H) | |||||||||
| Net weight | 7.2kg | |||||||||
| Power supply | AC220V 50Hz DC5V-2A | |||||||||
