- can be installed 8 blue lever or paddle lever.
- can install 8 dissolution cups.
- sampling needle with automatic lifting function
- Host operating parameters can be preset and automatically store, no need setting on next time.
- Speed control used subdivision power driver stepper motor, accurate & smooth operation, low energy consumption.
- Constant temperature water bath with built-in PT1000 sensors, PID control, can be easily corrected error with a software.
- Timer function displays the current sampling time points, the cumulative total time of sampling points, different sampling period and countdown
- With self-test function and automatic protection function, given a variety of fault signal.
- Can be connected with micro-printer.
- Having USB storage function, the experimental data retention for viewing.
- Chip program can be upgraded at any time.
Specifications
- paddle swings: ≤0.5㎜
- turn blue swings: 1≤㎜
- speed range: 25-250 rev / min
- Speed Resolution: 1 r / min
- steady speed error: ≤ ± 1%
- thermostat range 🙁 RT) -45 °C
- Temperature Resolution: 0.1 °C
- heating power: 1000W; temperature error: ≤ ± 0.1 °C
- Timing cumulative time: up to 5999 minutes, the countdown
- sampling cycle time: Up to 10 different sampling period, the countdown
- sampling cycle time: up to 5999 minutes, the countdown
- Power: AC220V ± 10%, 50Hz, 1000W
- Working conditions: temperature 0-40 °C, relative humidity ≤80% HR
